Automatic secondary packaging machine for rice brick

Intelligent self diagnosis system
Automatic secondary packaging machine for rice brick has a built-in real-time monitoring module, which automatically triggers audible and visual alarms and displays solutions when faults occur, reducing the risk of equipment downtime and improving maintenance efficiency.
Flexible production design
- One click type change: the modular structure supports the switching of packaging specifications within 10 minutes, which is suitable for the needs of different sizes of rice bricks.
- Dual mode bag Library: automatic secondary packaging machine for rice brick is equipped with conventional bag Library (about 250) and bail bag Library (about 380) as standard. When the bag is missing, it will automatically alarm and suspend the feeding to avoid the risk of empty bag.


Quality assurance technology
- Soft bag detection system: automatic secondary packaging machine for rice brick uses high-precision sensors to detect the integrity of packaging in real time and automatically eliminate damaged/air leaking soft bags.
- Independent negative pressure control: the automatic secondary packaging machine for rice brick bag taking and bag opening system is equipped with an independent vacuum generator, and the air sources do not interfere with each other, so it can still operate stably even if there is air leakage at one side.
Multi mode production compatibility
- Dual station output: automatic secondary packaging machine for rice brick supports bagging mode (automatically completing material bagging and sealing) and straight through mode (materials are directly output through the conveyor belt), which can be flexibly switched according to the requirements of the production line.
- Upstream and downstream online: automatic secondary packaging machine for rice brick can seamlessly connect with vacuum equipment to ensure continuous and controllable discharge of materials.

|
Name |
Technical Parameters |
|
Rice Brick Authorized Dimensions |
Front Width: 75 - 235mm Thickness: 36 - 85mm Height: 75 - 330mm |
|
Packing Capacity |
Regular Bags: 900 - 1000 Bags/Hour Loop Handle Bags: 850 - 950 Bags/Hour |
|
Bag storage capacity |
Dual-mode Bag Magazine, Regular Bags: Approx. 250 Bags, Loop Handle Bags: Approx. 360 Bags |
|
Power Supply |
AC380V Three-phase Five-wire System, 5kW |
|
Air Consumption |
0.6MPa, 0.35m³/min |
|
Working Temperature |
0 - 40℃, Relative Humidity: <90% |
|
Equipment Dimensions(LxWxH) |
2627×2190×2018mm |
