1, Full process automation, efficient and stable production
Integrated intelligent operation
- The 0.3KG bean vacuum shaping and packaging machine integrates the functions of automatic bag loading, bag feeding, metering, filling, shaping, vacuum sealing and finished product output, and supports the synchronous or independent operation of two stations (box 1/box 2), which improves the production capacity.
- The 0.3KG bean vacuum shaping and packaging machine adopts an intelligent identification system to monitor the packaging status in real time, automatically match the production parameters and reduce manual intervention.
Precise measurement and flexible production
- The three-level feeding technology combined with high-precision electronic quantitative scale strictly controls the error within ± 2G, ensuring the accuracy of bean measurement and avoiding the waste of raw materials.
- The fixed mold design supports fast switching of 300g-5000g full specifications, and calls preset parameters with one key through the memory formula function to meet the requirements of diversified orders.
Intelligent bag supply and quality control
- The continuous circulation system of multi bag storehouse can dynamically expand the capacity of bag storehouse according to the production demand, reduce the bag changing frequency, and ensure the smooth opening of bags by combining with the automatic straightening technology.
- It is equipped with an automatic rejection device. If the bag opening fails, the system will automatically isolate the problem packaging and restore the bag supply process. There is no need to stop the whole process to ensure the independent operation of two stations.
2, Innovative technology optimization, significant cost reduction and efficiency increase
Original automatic unpacking Technology
The rapid separation of the packaging bag and the mold can reduce the material stagnation, reduce the loss rate, and ensure the stability of continuous production.
Flexible production mode
Provide full-automatic/semi-automatic dual-mode switching:
- Full automatic mode: the whole process is unattended, suitable for large quantities of standardized orders;
- Semi automatic mode: retain the manual intervention interface and flexibly adapt to small batch or multi specification orders.
3, Smart IOT enabling, digital management upgrading
- The 0.3KG beans vacuum shaping packaging machine has a built-in Siemens DP communication module, which supports remote equipment monitoring, fault diagnosis and firmware upgrade, reducing on-site maintenance costs.
- Real time upload of production data (such as production capacity, yield and energy consumption) through the Internet of things platform to help the digital management of the workshop.
|
Model |
HS-600-B Fully Auto Brick Shape Vacuum Packing Machine |
|
Packing Range |
0.3-5.0kg |
|
Packing Capacity |
550-650 bags/hour |
|
Power Supply |
AC380V Three-phase-five-wire system,4.5kW |
|
Air Consumption |
0.6MPa,0.36m³/min |
|
Bag Storage Capacity |
≈400 pieces |
|
Working Temperature |
0-40℃ |
|
Relative Humidity |
＜90％ |
|
Measuring method |
High precision electronic quantitative scale
|
|
Division Value |
1g |
|
Applicable Packaging Materials |
Customized composite film packaging bags |
|
Vacuum degree |
Relative vacuum -0.06~-0.08Mpa |
|
Equipment Dimensions(LxWxH) |
2194*3840*2538mm |
