The 1.25Kg nut vacuum shaping and packaging machine
1. Full process automation, emphasizing both quality and efficiency.
The 1.25Kg nut vacuum shaping and packaging machine supports manual assisted bagging, and the entire process is automated to complete weighing, testing, filling, vacuuming, shaping, packaging, and finished product output. Through intelligent control system, dynamic parameter adjustment is achieved to ensure packaging sealing, appearance flatness, and product preservation effect, significantly improving production efficiency and finished product qualification rate.
2. Industry's first dual station design with four measuring scales, expert in fast small packaging.
The nut vacuum shaping and packaging machine is designed for small-sized materials weighing up to 1.25kg. It innovatively uses double tube feeding technology and a four metering scale system to achieve synchronous output of four packages of products in a single cycle, with a packaging speed of up to 1200 packages per hour. Dual workstation collaborative operation breaks through the bottleneck of traditional single line production capacity and perfectly adapts to the refined packaging needs of industries such as food and medicine.
3. Dual screen dual pump interactive system, more intelligent operation.
The 1.25Kg nut vacuum shaping and packaging machine is equipped with dual independent touch screens, supporting multitasking parallel operation and real-time monitoring, with a simple and intuitive interface; The dual vacuum pump configuration can intelligently switch or work together according to process requirements, ensuring high-speed operation stability and simplifying equipment maintenance processes, achieving the ultimate experience of human-computer interaction.
4. Global first-line supply chain, the cornerstone of quality.
The core electrical components of the 1.25Kg nut vacuum shaping and packaging machine are selected from internationally renowned brands such as Siemens and Schneider, combined with modular design to ensure the long-term stability and anti-interference ability of the equipment, and reduce the failure rate.
5. High precision vibration control, precise and worry free filling.
The 1.25Kg nut vacuum shaping and packaging machine is equipped with advanced vibration compensation algorithms to accurately control the material filling process, effectively solving the problems of layering and measurement deviation that traditional equipment is prone to. It has high filling accuracy and is particularly suitable for precise packaging of materials with different flowability such as powders and particles.
The 1.25Kg nut vacuum shaping and packaging machine is widely used in fields such as food, chemical, and pharmaceutical. With the concept of "intelligent production+flexible manufacturing", it helps enterprises achieve cost reduction, efficiency improvement, and quality upgrading. It is the innovative choice for the packaging process in the Industry 4.0 era.
|
Name |
Equipment parameters |
|
Packing Range |
0.3-5KG |
|
Packing Capacity |
0.3-1.25KG,with a speed of approximately 1000-1200bags/hpur
|
|
1.25-5KG,with a speed of approximately 500-600bags/hour
|
|
|
Packing Accuracy |
±2g |
|
Division Value |
1g |
|
Power Supply |
AC380V, Three-phase-five-wire system,4KW |
|
Air Consumption
|
0.6Mpa,0.5m³/MIN |
|
Measuring method |
High precision electronic quantitative scale
|
|
Working Temperature |
0-40℃ |
|
Equipment Dimensions(LxWxH) |
2050 *1370*2453 mm |
