Flat Shape Cat Litter Vacuum Packing Machine
Innovatively adopts a manual sitting-type bagging method combined with a high-speed cyclic multi-station structure, realizing full-process automation from automatic weighing, vacuum extraction, sealing and shaping to finished product output. Compared with the common bent-over operation mode of double-station equipment in the industry, the sitting-type bagging greatly reduces labor intensity, prevents workers from feeling fatigued during long-time operation, and effectively ensures stable production capacity.
Equipment Parameters
|
Name |
Technical Parameters |
|
Packing Range |
0.5-10.0KG (measured in terms of rice) |
|
Packing Capacity |
Approximately 500-600 bags/hour (varies with different materials) |
|
Packing Accuracy |
±2g |
|
Division Value |
1g |
|
Power Supply |
AC380V, Three-phase-five-wire system,5.5Kw |
|
Air Consumption |
0.6MPa, 0.4m³/min |
|
Measuring method |
High precision electronic quantitative scale
|
|
Working Temperature |
0-40℃,Relative Humidity：＜90% |
|
Equipment Dimensions(LxWxH) |
1553*2465*2590.5mm |
Flat Shape Cat Litter Vacuum Packing Machine
Key Functions & Features:
The machine body is made of 304 stainless steel, which is suitable for food processing scenarios and easy to clean and maintain, laying a solid hygienic foundation for rice packaging.
The core metering and vacuum systems demonstrate distinct technical advantages. Equipped with a 10kg double-scale cyclic metering feeding system and combined with high-precision vibration-controlled multi-stage feeding technology, the machine features fast weighing speed and ultra-high accuracy with an error margin of only ±2g. Its proprietary patented technology ensures that metering is not affected by voltage fluctuations.
It is also fitted with a high-power vacuum pump and an air storage tank, which significantly enhance vacuum extraction efficiency and help achieve a packaging speed of 500–600 bags per hour. Supporting multiple modes including vacuum packaging, sealing-only and weighing-only, the machine meets the packaging needs of rice with different specifications ranging from 0.5kg to 10.0kg.
The user-friendly operation adapts to production requirements in various scenarios. It adopts a large-size Chinese touch screen with built-in parameters for ten specifications that can be directly called up.
Combined with a minimalist operation interface and rich software functions, it enables one-click switching of packaging specifications. The flexible recipe setting and multi-level user permission management mode not only facilitate quick mastery by novice operators but also ensure the security of production data.
With a compact dimension (1553mm*2465mm*2590.5mm), the machine is adaptable to different factory layouts and can be put into use without large-scale plant renovation.
Dual guarantees of quality and safety highlight its reliable performance. The whole machine adopts world-class electrical components such as Megmeet PLC, Schneider contactors and Omron relays from Japan, ensuring stable and durable performance. The electronic control system meets the IP4 protection standard, with weak and strong current lines routed separately and not exposed, further enhancing operational safety. Widely applicable to scenarios such as rice processing plants and grain & oil distributors, the machine can not only extend the shelf life of rice and lock in its original flavor through vacuum packaging, but also reduce comprehensive production costs with its efficient and stable performance, making it an optimal equipment choice for the grain and oil processing industry.
