MH-1000 micro dual packer
1. Excellent Sealing Performance And Efficient Packaging Capacity
- Dual cylinder independent sealing system: MH-1000 micro double packer is equipped with two independent sealing cylinders, which realize double sealing guarantee through precise pressure control to ensure tight sealing without leakage and clear and beautiful sealing line.
- Fast response and stability: optimize the pneumatic structure design, seal quickly, combined with the compact fuselage layout, to meet the needs of high-frequency continuous operation.
- Low noise operation: silent pneumatic components and shock absorption structure are used to reduce the noise of equipment operation and create a comfortable operating environment.
2. Intelligent Plc Control System
- Full automatic process management:MH-1000 micro double packer is based on PLC programmable controller to realize the whole process automation of sub packaging, sealing and counting, reduce manual intervention and improve production efficiency.
- Convenient maintenance design: modular structure with fault self diagnosis function can quickly locate problem modules and reduce maintenance costs and downtime.
3. Intuitive Touch Human-computer Interaction
- High definition touch screen: MH-1000 micro double packer adopts industrial touch panel, with simple and intuitive interface, which can be used by operators quickly.
- Flexible process adjustment: through the touch screen, you can modify the sub packaging parameters in real time, call the preset process library, and adapt to the multi variety and small batch production mode.
4. Compact Structure And Stability
- High integration fuselage: the size of MH-1000 micro double packer is optimized to 1218mm × 597mm × 1928mm (length × width × height), saving production space and facilitating mobile deployment.
- Rigid frame design: all stainless steel fuselage with reinforced base can effectively suppress vibration and ensure the stability of the equipment under high-speed operation.
|
Number |
Name |
Equipment parameters |
|
1 |
Power Supply |
AC 220V/50HZ ,0.8KW |
|
2 |
Sealing line speed |
0-16m/min |
|
3 |
sealing width |
10mm |
|
4 |
Temperature range |
0-300℃ |
|
5 |
Bag size |
Length120-350mm,width 100-265mm |
|
6 |
Packaging speed |
1000 bags/hour |
|
7 |
Division Value |
1g |
|
8 |
Working Temperature |
0-40℃ |
|
9 |
Equipment Dimensions(LxWxH) |
1218mm*597mm*1928mm |
